Package Include:

1 X 3-Row Aluminum Radiator w/Radiator Cap

1 X Aluminum Shroud

1 X 16" Fans (Includes mounting kits)

Application:

For 1917-1927 Ford Model T Bucket Chevy Engine

Radiator Size：

Material：Aluminum
Core Row： ( 3 Row Core)
Radiator cap included
Core Dimensions: 18" (H) x 18-1/2" (W)
Overall Dimensions: 24" (H) x 22-1/2" (W)
Inlet Location：On Driver Side
Outlet Location：On Passenger Side
Inlet: 1-1/2" Out:  1-3/4"

Transmission Cooler: Included

Aluminum Shroud and Fans:

The New Design fan and the  fan shroud effectively drive the heat over and out the engine compartment rather than thrusting it into the front of the engine. The fan shroud basically houses the fan blades securing it in place and keeping it from damaging the other engine components that may disturb the smooth and even operation of the engine. With excellent operating temperature management, allowable levels of engine temperature are stabilized. Investing in proper maintenance though will considerably benefit the ride and driving quality in maintaining the ideal working conditions of the engine.

16" Fan

Voltage: DC 12 Volts

Maximum Fan CFM: 2150 cfm

Wattage: 120 Wattage

Thickness (in): 2.950"

Number of Blades: 10 S-Type blades

Maximum Fan RPM: 2,250 rpm

Amp Draw: 10 amps

Description:

This Aluminum Radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This Aluminum Radiator is at least 30%-45% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.
