XTOOL INPLUS IP919 Bidirectional Scan Tool---2025 New Updated Version
✅ 2025 Newly Added FCA AutoAuth ，✅ CAN FD & DOIP Diagnostic Protocols, ✅ 42+ Reset Functions, ✅ Advanced E*CU Coding, ✅ Pre/Post Scan, ✅ ADAS, ✅ PMI,✅ Guide Function,✅ Auto VIN Scan + One Click Update✅ Diagnostic Report 2.0, ✅ Topology Mapping, ✅ Full System Diagnostic, ✅ Bi-Directional Control,✅ 4000+ Actuation test,✅ 3 Years Free Update ，✅ Wireless WIFI ✅ 24+ Languages ✅ Better Hardwareetc.
More details about IP919's features：
▶️ 1. 2025 New Add Extra Protrcols: FCA AutoAuth Protocols-supports access to the Security Gateway Module on 2018 and For Chrysler/Dodge/Jeep vehicles.(Note: Customers need to register the FCA account by themselves.)
▶️2.Wireless WIFI Connection Diagnostics:Simply plug the VCI into the OBD interface for rapid data transfer, faster than conventional wireless BT scanners,improving the speed and stability.
▶️ 3. Advanced OE-level Functions: INPLUS IP919 can do basic diagnostic functions like reading & clearing fault codes and checking vehicle live data and retrieve ECU info in order to locate issues hidden inside vehicles.
▶️ 4. More than 42+ Resets Functions:Fix vehicle's maintenance issue to make maintenance a lot easier,such as: Oil Reset, EPB, SAS, DPF, BMS Reset, Throttle, TPMS Reset...
▶️5. Bi-Directional Control:Supports control various vehicles components send commands to systems/components to test their working status, without using the vehicle controls. to perform active tests like EVAP test, idle relearn, injector test, cycling ABS motor pump, A/C Clutch Switch On/Off...
▶️ 6. Advanced E*CU Coding:Flash the hidden features, Personalized Settings, or disable the annoying functions; Reprograms the adaptive data for certain components after repairs or replacements
▶️ 8. Intelligent Topology Mapping:Just one click to display all fault codes, executive functions and view live data in graphing directly
▶️ 9. Support CAN FD/DOIP Protocols:Compatible More CAN FD Protocol Vehicles (For GM Vehicles After 2020) (CAN FD Adapter NO Needs Buy Separately); DOIP Function Compatible For BMW E/F/G Chassis, Jaguar, Land Rover vehicle makes.
▶️ 10. 2024 Advanced Functions Also Include:PMI (Programmable Module Installation) + ADAS Calibration
▶️ 11.GUIDED FUNCTIONS: Provide instructions step by step when diagnosis or performing complicated functions. (For VW/For Audi/For Skoda) Guided Functions .
▶️12. Auto VIN Scan + One Click Update + Diagnostic Report:AutoVIN functions allowing you to quickly figure out Vehicle Identification No. (VIN) to perform fast diagnostic.
▶️13. More Than 150 Brands and 20000+ Cars supported + 24 Languages:
▶️14. Better Hardware:✔️Android 10.0 Systems ✔️ 10.1 Touch Screen✔️ 6400mAh 7.2V Battery✔️ 1920*1200 Resolution✔️ 8 Core 4.0GHz CPU Processor ✔️ 8G + 128G--bigger storage,save more vehicle documents and customer data.
▶️ 15. 3 Yeard Free Update + 2 Years Warranty + Lifetime Tech Support:Long after-sales service, quality assurance, trustworthy.
▶️ 16. Expand More Functions: ✔️XV100 digital inspection camera to in-dept inspection to fuel tank system, engine, invisible angle, etc.
▶️17. Pre Scan & Post Scan with Report V2.0: With pre & post scan to ensure vehicle systems that impact driver and passenger safety, comfort and convenience are correctly diagnosed and repaired to work as intended. Diagnostic Report v2.0 allow adding your auto shop logo and repair pictures to the diagnostic report.
▶️18.8-In1 Live Data Graphing:Allows you to view the live PID(parameter identification data) data of vehicle’s computer module(s) in text, graph to check the status of various sensors.
ADVACNED E*CU CODING & CONFIGURATION + GUIDE FUNCTION + OFFLINE PROGRAMMING
- E*CU Coding: Ensuring seamless ECU matching, coding, and personalized car settings. (Fit for VW / for Audi / for Skoda)
- E*CU Configuration: Make full use of hidden features or disable car’s annoying functions like Auto Side Mirrors, Disable Seat Belt Alarm Beep.(For BMW/For VW/For Audi/For Skoda/For Toyota/For Lexus/For Scion/For Mazda/For Ford/For Lincoln)
- Programmable Module Installation (Offline Programming): Facilitating ECU software/firmware updates, new module programming, etc.( for Ford / for Lincoln, and for Mazda )
- Guided Functions: Provide instructions step by step when diagnosis or performing complicated functions. (For VW/For Audi/For Skoda)
With Topology Map to View the Communication Structure Between Modules Clearly:
XTOOL INPLUS IP919 automotive diagnostic scan tool enables a data link to the electronic control system of the test vehicle for vehicle diagnosis. The application performs functional tests, retrieves vehicle diagnostic information as trouble and event codes and live data for various vehicle control systems, such: ABS, SRS, Engine, Transmission, Brake System, Emission System, Fuel system, Light system, Wiper System etc.
With the basic diagnostic functions integrated inside the device,IP919 can easily check the issues happended before,within and after the programming process.
⏩Read Codes: Read the fault code, fault description, and fault code status within the selected module.
⏩Clear Codes: Clear the fault code in the selected module and turn off the fault light on the meter.
⏩Read Live Data: Reading all the data flow information contained within the selected module.
⏩Read Freeze Frame: Accompanied by fault codes, record the state of fault codes appearing, to provide help for vehicle fault repair.
⏩Read E*CU Information: Read the version information, model information, etc. of the selected module.
- 1-Oil Reset：Reset service intervals after oil change and turn off the oil light.
- 2-EPB Reset: Reset brake pads after replacement of brake system.
- 3-SAS Adjustment: Perform calibration of the steering angle sensor.
- 4-BMS Reset：Reset the BMS system after replacing the vehicle battery.
- 5-Throttle Relearn: Enables you to make initial settings to throttle to adjust the amount of air intake.
- 6-ABS Bleeding: Perform ABS Brake Bleed function to cycle the ABS pump to bleed the air out of the ABS.
- 7-Injector Coding: Coding injectors after replacement.
- 8-Gearbox Match: Reset the adaptive shifting points in your automatic Transmission Control Unit.
- 9-Crank Sensor Relearn ：Learn the crankshaft position sensor to ensure normal operation of the engine.
- 11-TPMS Reset：Reset the tire pressure monitoring system and turn off the tire pressure warning light.
- 12-Power Balance：Conduct tightness and balance tests on the cylinder and adjust the power balance of the cylinder.
- 13-Transport Mode：Transportation mode can be released through the diagnostic tool.
- 14-Coolant Bleeding ：Activate the electronic water pump to check for fault points in the cooling system/drain the air in the cooling system.
- 15-A/F Reset：By flashing the data parameters inside the E#CU, the engine torque is changed to achieve the maximum horsepower of the engine.
- 16-NOx Reset; 17-Suspension; 19-DPF;20-Tire Size Reset; 21-Headlight; 22-Seat Match; 23-EEPROM; 24-ECU Configurations; 25-Stop/Start Reset; 26-Windows Initialization; 27-Airbag Reset; 28-Language Change; 29-Odometer Read; 30-Control Unit Reset; 31-Rain/Light Sensor; 32-A/C Relearn; 33-HV Battery; 34-VGT Relearn; 35-Write VIN; 36-FRM Reset; 37-EGR Relearn; 38-AdBlue Reset; 39-SRS; 40-Clutch Adaption; 41-Speed Limit; 42-ADAS...
- 24/7 Hours Online Support:You could contact us via ebay message if you have any questions.
- 3 YEARS SOFTWARE UPDATE ONLINE: You can still use the scanner normally even when the free updates period expires.
- SCREEN SIZE: 10.1-inch Large Size Screen with 1920*1200 resolution.
- MEMORY: 8G+128G bigger storage,save more vehicle documents and customer data.
- CONNECTION METHOD: Wire/WIFI(VCI)
- BATTERY:6400mAh 7.2V for improving charging speed and extended battery life.
- PROCESSOR: 8 Core 4.0 Ghz
- OPERATE SYSTEM:Android 10.
- SPECIALIZED CHARGER BASE GUIDE: ✅Green Light → Lit Up when fully charged.🔴Red Light → Lit up when device is being charged.🔵Blue Light: →Lit up when device power on.；→The device is still on the base when fully charged.
