Material: AA5052 Aluminum
High Performance Racing Spec.
3-Row of tubes Core Racing Design
Core Size: 22.88 In. x 18.13 In.
Inlet Hose Connection: 1.31''
Outlet Hose Connection: 1.56''
Transmission Oil Cooler: Yes
Engine Oil Cooler: NO
Please Check the Size Before You Buy!
Application:
Manufacturer Part Number: 2707, CSF3471, 15120862, 15199308, 21524, 2219057, 433859, 52491742, 52491743, 8012707
Fan Specification:
Diameter : 16'' (Blade to Blade)
Voltage: DC 12 Volts
Wattage: 120W
Number of Blades: 10 S-Type blades
Maximum Fan CFM（Cubic Feet per Minute）: 3,000 cfm
Maximum Fan RPM（Revolution(s) Per Minute）: 2000±10%
Amp Draw: 10amp
Fan Thickness: 2.95"
S-Type Blade pull push design, to make air flow more efficient and bring more cooling Effect
Powerful 120 watt motor will keep your engine cool.
Thermostat Kit:
Work with any 12 volt system.
Universal fit for any automotive vehicle and electric fan.
Activates by grounding electric fans at preset temperature.
185'F turn-on temperature, 165'F turn-off temperature.
3/8" NPT thread-in brass probe included.
Probe typically threads into radiator, water outlet or manifold.
Thermostat Relay Kit Instructions：
RED + connect directly to battery.
WHITE wire to ignition switch power source.
BLACK goes to thermos switch.
BLUE wire goes to the Fans.
AA5052 Aluminum Shroud+Fan：
Our custom-made AA5052 aluminum fan shrouds are manufactured to fit our ALLOYWORKS and ASI
PERFORMANCE radiators. These fan shrouds are fabricated for use with our
electric cooling fans but allow for use with most low profile electric
fans.
The
fan and the fan shroud effectively drive the heat over and out the
engine compartment rather than thrusting it into the front of the
engine. The fan shroud basically houses the fan blades securing it in
place and keeping it from damaging the other engine components that may
disturb the smooth and even operation of the engine. With excellent
operating temperature management, allowable levels of engine temperature
are stabilized. Investing in proper maintenance though will
considerably benefit the ride and driving quality in maintaining the
ideal working conditions of the engine.
1.Shuttered design AA5052 fan shroud to guaranteed airflow passes high efficiently.Make your engine bay perfect.
2. S blade fans, Push or Pull Type design,lightweight Plastic Durable Material.
This AA5052 Aluminum Radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This AA5052 Aluminum Radiator is at least 30%-45% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.
1.Made of AA5052 aircraft aluminum,stronger than other popular alloys and has increased corrosion resistance.
2.Brazed core technology to guarantee optimum performance and dependability.
3.AA5052 Aluminum 2mm thick tanks and fittings, Ensure it's hard and durable.
4.Higher density core: cooling rows are spaced 3/8" apart, giving you 25% more rows within the core than other aluminum radiators.
5.14-16 cooling fins per inch, giving you approximately 1500 more cooling fins than other aluminum radiators, throws off much more heat.
-
ALLOYWORKS radiator is a performance aftermarket car parts company providing a variety of aluminum radiator for all sorts of makes and models.
-
Shop with us with confidence you would be receiving the best quality products for the value.
-
No matter if it's for a car or truck we have exactly what you're looking for!
Browse through our eBay store if you wish to find out more of what we have to offer. thanks
Paypal ONLY --the easiest and most secure way to pay on line
- Items will be shipped 24 hours of payment verification.
- We do not offer local pick ups for any orders made through eBay.
- We use United States Postal Service (USPS), United Parcel Service (UPS) or Federal Express (FedEx) to ship our packages.
- Ground Carriers do not deliver to PO BOX or areas : Hawaii (HI) , Alaska (AK) , Puerto Rico (PR) , Army Post Office (APO) , Fleet Post Office (FPO), PR , HI , AK , APO , FPO ,Canada and International Countries.
-
We accept return in 30 days and appreciate communication in advance!
- All return items MUST be in brand new condition which means the item is never installed and kept in the original packaging.
- You must contact us to request a Return Authorization Number (RA#) before you send anything back. With RA#, we may address return issues with high efficiency. Without RA#, we may fail to find your transaction. Appreciate your understanding!
Shipping Damage
- Shipping damage is any item/package suspected of being broken or damaged in anyway during the shipping process. We purchase full insurance for this, however the damage must be reported to us within 3 days of receiving the package.
