- Fully passive, high-performance transformer design; no battery required
- Converts 50kΩ inputs into 600Ω balanced outputs
- Switchable input attenuation (0, -20, -40 dB) helps you keep from overloading the inputs
- Switchable low-pass filters (-3 dB @ 30 kHz) reduce RF interference and computer noise
- Phase invert switches let you switch signal polarity at the source
- Ground-lift switches help eliminate hum, and fully isolate the inputs from the chassis and outputs
- Balanced XLR outputs for connection to mixers, audio interfaces, and other low-impedance devices
- Low-pass filters help eliminate RF interference and digital computer noise
- Rugged and compact extruded-aluminum case
| Brand | Art |
| MPN | DUALZDIRECT |
| Type | Passive Direct Box |
| Type | Passive, Dual |
| Input Connections | 2 x 1/4 TRS phone (unbalanced); 50kΩ |
| Output Connectors | 2 x XLR male; 600Ω 2 x 1/4 TRS phone (pass through) |
| Frequency Response | 10 Hz - 50 kHz, ± 0.5 dB @ +4 dBu |
| THD | 0.01% typical @ 1 kHz, +18 dBu / <.05% @ 100 Hz, +18 dBu |
| Channel Separation | > 80 dB (typical) |
| Controls | 2 x Low-Pass Filter (switchable); -3 dB @ 30 kHz 2 x Input Attenuation (switchable); (0, -20, -40 d |
| Dimensions (WxDxH) | 4.6 x 3.9 x 1.85 (117 x 99 x 47 mm) |
| Weight | 0.88 lbs (0.40 kg) |
