Features > USB Video Class(UVC) compliant
> Designed for face recognition and live detection
> IR/RGB 1080P
> HDR Function
> Detection range up
Specifications
> DSP IR Camera: AKXXXXX
RGB Camera: EMXXXX
> Image Sensor IR Camera: JX-F32
RGB Camera: AR0230
> Field of View IR Camera: Diagonal: 86°, Vertical: 49°, Horizontal: 78°
IR Filter: Tavg?90%; 850±10nm
RGB Camera: Diagonal: 95.8°, Vertical: 58.2°, Horizontal: 87.8°
IR Filter: Tavg?97% 440~635 nm
> Active Pixels 1920 x 1080
> Pixel Size 3um x 3um
> Compression Format YUV/MJPG
> Focus Type Fixed focus
> Operating Temperature -30? to +70?
> OS Support WinXP/Vista/Win7/Win8/Win10/Win11
Linux with UVC?above linux-2.6.26?
Android 4.0 or above with UVC
> Dimension DCEA23-TC1-6R : 40.0mm (L) x 28.6mm (W) x 16.5 mm (H)
DCEA23-HK1-6R : 40.0mm (L) x 28.6mm (W) x 23.0 mm (H)
> Shutter Type Electronic Rolling Shutter
> Power Consumption 5V
Applications
> Door/Gate Security System
> Access Control System
> ATM machine
> KIOSK / POS Equipment
> Automatic Vending Machine
# Customized available
# Technical support available
# Order included one USB Cable 75cm
