Specifications Style: Modern Shape: Rectangular Color: Black Material: Aluminium, Silicone Process: Painting Plug Type: US Standard Mount Type: Tabletop Assembly Required: No Power Source: Corded Electric Input Voltage: 0-180V Input Current: 0-30A Power: 200W Constant Voltage Mode Range: 0.1~19.999V, 0.1~180.00V Resolution: 1mV, 10mV Accuracy: ±(0.05% + 0.02% FS) Constant Current Mode Range: 0~3.000A, 0~30.00A Resolution: 1mA, 10mA Accuracy: ±(0.05% + 0.05% FS) Constant Resistance Mode Range: 0.05Ω-4.50kΩ Resolution: 10mΩ, 1Ω Accuracy: ±(0.1% + 0.5% FS) Constant Power Mode Range: 0-200W Resolution: 10mW Accuracy: ±(0.1% + 0.5% FS) Dynamic Testing Function Mode: CC, CV T1 & T2: 0.05s–99.999s Battery Testing Function Discharge Mode: CC, CR Maximum Discharge Capacity: 9999Ah Resolution: 1mA, 10mA, 10mΩ, 1Ω Product Size: 24*7.5*16cm/9.5*3*6.3in Package Size: 30*21*14cm/11.81*8.27*5.51in Gross Weight: 1.7kg/3.75 lbs Net Weight: 1.61kg/3.55 lbs Package Included 1* Electronic Load Tester 1* Power Cord 1* English Manual
Key Features
High-class Materials: The product is made of aluminum and silicone, featuring a painting process that ensures high strength and abrasion durability, guaranteeing a long service life.
Nine Commonly Used Test Modes: The product supports four basic measurement modes—CC, CV, CR, and CP—as well as five specialized test modes: battery, dynamic, sweep, list, and short-circuit. The dynamic test mode can detect the dynamic output performance of power supplies; the sweep test mode can verify the output continuity of power supplies within a certain range; the list mode can simulate various load state changes; and the short-circuit test mode simulates load short-circuit conditions, meeting diverse testing needs.
High Safety: Equipped with multiple protection functions such as over-voltage, over-current, over-power, and over-temperature protection, it allows flexible setting of over-voltage and over-current parameters to effectively protect the load. It also features an intelligent fan speed control function to reduce operational fan noise, multiple heat dissipation holes to accelerate cooling, and input polarity reverse indication to prevent device damage and safety hazards.
High-Precision Testing: This product delivers high resolution and accuracy of 1mV/10mV and 1mA/10mA for DC programmable electronic loads, enabling precise testing.
Remote Operation: The product supports USB interface communication with a computer for remote operation. During remote connection, a key lock function prevents misoperation.
Details
Slip-retardant Feet: Four slip-retardant feet ensure stability and prevent tipping during use.
LCD Display: Equipped with an LCD display with an adjustable backlight design, it makes operation more user-friendly.
Application
This product is widely applicable to production line testing in industries such as chargers, switching power supplies, linear power supplies, and batteries, making it an indispensable tool for power product development, production testing, and quality control.
