Description:
1.3 frequency range, FM (FM) 87-108MHz, medium wave (MW): 522-1620KHz, short wave (SW): 4.75-21.85MHz
2. Small distortion, the maximum output distortion is ≤10%.
3. Low power consumption, clock mode standby quiescent current only ≤ 25uA
4. Fully functional and easy to operate
5. Support timer on/off switch
Frequency range FM: 87-108MHz MW: 522-1620KHz SW: 4.75-21.85MHz
2. Noise limiting sensitivity FM: 30dB ≤ 8dBu AM MW: 26dB ≤ 60dBu AM SW: 26dB ≤ 32dB
3. FM (FM) stereo separation: 98MHz ≥ 20dB
4. Signal-to-noise ratio FM (FM): 98MHz ≥ 50dB MW (MW): 1000KHz ≥ 40dB
5. Maximum output power headphones: ≥ 100mW * 2 speakers: 4 Europe / 5W
6. Instantaneous maximum working current: ≤ 500mA
7. Maximum output distortion: ≤ 10%
8. Clock mode standby quiescent current: ≤ 25uA (lithium battery fully charged can standby for 1 year)
9. Power supply: 3.7V/1000mAH lithium battery (product does not include the battery) 10. PCBA size: 58x49x10mm
Warm tips:
Radio is the role of receiving the signal emitted by the radio station, different listening environment reception effect is not the same. For some areas near the large signal station or building, due to signal interference or shielding and other circumstances, when listening to a radio wave, will be mixed with murmurs or all murmurs, this situation can not be eliminated! When listening, it is recommended to stay away from household appliances and adjust the antenna direction as close to the door or window position as possible!
Product list: 1X radio module
