Module Ultrasonic Flow Meter Flowmeter with High Temp Transducer DN300~6000mm

This type Ultrasonic Flowmeter is package with High Temperature Transducer TL-1-HT Large (size: 97*54*53mm) for Pipe Diameter DN300~6000mm, High Temperature : -30~160℃

Please note that the power converter is optional, the power converter is used to convert the AC220V power supply to DC24V. If you need, you need extra payment USD35.

Technical Specifications:
Accuracy: ≤1%
Velocity range: 0~±10m/s, Bi-directional measurement
Pipe size: DN300 to 6000mm
Temperature: -30~160°C
Type of liquid: Single liquid can transmit ultrasound, such as water, sea water, sewage, oil, alcohol, etc.
Pipe material: Steel, stainless steel, cast iron, copper, PVC, aluminmum, glass steel, etc. Liner is allowed.
Signal output:

• 1 way 4-20mA output
• 1 way OCT pulse output
• 1 way Relay output
