Application:
Land Rover Range Rover L322
Autobiography Sport Utility 4-Door 5.0L 2012
Base Sport Utility 4-Door 5.0L 2010-2012
Base Sport Utility 4-Door 4.4L 2003-2004
HSE Lux Sport Utility 4-Door 5.0L 2012
HSE Sport Utility 4-Door 5.0L 2010-2012
HSE Sport Utility 4-Door 4.4L 2003-2009
Supercharged Sport Utility 4-Door 5.0L 2010-2012
Supercharged Sport Utility 4-Door 4.2L 2006-2009
OE Number:
RNB000070,RNB000750,RNB500550,
RNB501350,RNB501410,RNB501530,
LR032570,LR051702,
RNB000060,RNB000740,RNB500540,
RNB501340,RNB501400,RNB501520,
LR032563,LR051700
Generation & Evolution??
Range Rover
Classic First generation (1970-1996)
P38A Second generation (1994-2002)
L322 Third generation (2002-2012)
L405 Fourth generation (2012-present)
Expanded Line
Range Rover Sport
L320 First generation (2005-2013)
L494 Second generation (2013-present)
SVR (2015 Pre-Facelift)
SVR (2018 Facelift)
Range Rover Evoque
L538 First generation (2011-2018)
L551 Second generation (2018-present)
Range Rover Velar
First generation (2017-present)
Platform Drive Layout
Front Engine-Four Wheel Drive Layout
Signs that your air suspension needs to be replaced include:
1.Abnormal Sounds
2.Poor Handling Stability
3.Air Leakage
4.Car Body Slant
5.Irregular Tire Wear
6.Over Bend
Note Before Installation:
1.To avoid the possibility of short circuits while working with electric components consult your owner's manual on how to disconnect your battery.
2.Consult your vehicle owner's manual, service manual, or car dealer for the correct jacking points on your vehicle and for additional care, safety and maintenance instructions. Under no circumstances should any work be completed underneath the vehicle if it is not adequately supported, as serious injuries and death can occur.
Removal Guideline:
1.Remove the shock retention nut from the top of the air strut assembly.(picture 11)

2.Remove the nut and washer as illustrated.(picture 12)

3.With the upper retention hardware removed, flip the strut over and locate the alignment pin on the bottom of the air spring assembly.(picture 13)

4.With a slotted screwdriver or other adequate tool, remove the lock washer from the locating post.(picture 14)

5.Remove the lock washer as illustrated.(picture 15)

6.Tap the bottom of the air spring with a soft faced mallet to disengage the o-ring seals.(picture 16)

7.Air spring as well as all o-rings and o-ring spacers are discarded. The only thing you will reuse is the shock itself. Disassembled view of shock.(picture 17)

8.Clean the shock of any debris before beginning installation of the air spring.(picture 18)

9.Removal complete.
Installation Guideline:
1.Install the new o-rings and o-ring spacers provided in 7 the kit in the same orientation as removed in step 7.
2.Install the provided bumpstop over the strut shaft in the depicted orientation.
3.Slide the gold washer over the threaded end of the shock.Ensure the perimeter “lip” Is facing downward away from the threads.
4.Slide the new air spring assembly over the shock. Make sure to align the plastic alignment pin on the air spring through the hole in the shock’s piston seat. After you have pushed the lower piston’s alignment pin through the shock’s spring plate, slide the external locking clip over the plastic pin to secure the air spring to the shock.
5.Push the upper black rubber mount over the shock’s shaft. Make sure to place the rubber seal in the correct orientation as depicted.
6.Slide the black washer over the treaded end of the shock.ensure the perimeter “lip” is facing upward and towards the nut.
7.Thread the m16nylon lock nut over the strut’s threaded shaft. You can tighten the nut using an impact wrench.
8.Install completed strut back into the vehicle in the reverse order of removal.
Depending on vehicle model, there are three possible build methods for your rebuilt arnott strut. Before proceeding with the build process,be sure to differentiate which air strut you are rebuilding and select the correct option.
Highlight:
1. 100% Air Tightiness testing
2. 24 hours air tightness test ≤0.02MPa
3. Anti-corrosion and provide a more consistent wear surface
4. Built to strict quality control standards
5. CNC Machined Components
6. Designed for Comfort Suspension
7. Direct replacement for OEM strut without modification
8. Easy to install
9. Eliminating abnormal sound
10. Gives the driver more control of ride
11. Good heat dissipation
12. It has a high compressive strength and good sound insulation to ensure our driving comfort and safety
13. Restore the original ride height and improve ride quality
14. Test more than 3 million times
15. Sturdy & Durable Material
Package Included:
Pair for Front Left & Right Air Suspension Spring Bags
Note:
1.Please double confim the compatibility as well as the OEM number before purchasing.
2.Instruction is not included. Professional installation is recommended
3.Please feel free to contact us for whatever we can help via eBay message; every message will be replied in 12 hours.
| Item Specifics | |
|---|---|
| Placement on Vehicle | Left Right Front |
| Type | Air Suspension Spring |
| Fitment Type | Direct Replacement |
| Size | Single Dimension(CM) 46.00(Length)*21.00(Width)*20.00(Height) |
| Single Weight(KG) | 5.580 |
| Upper Mounting Isolator Included | No Isolator Required |
| Lower Mounting Isolator Included | No Isolator Required |
| Upper Mount Type | Stud |
| Lower Mount Type | Base Cup |
| Included Hardware | Mounting Hardware |
| Drive Layout | Front Engine 4WD |
| Platform | L322 |
| Custom Bundle | Yes |
| Material | Iron Aluminium Alloy Rubber |
| Quantity | Pair |
| Manufacturer Warranty | 1 Year |
| OE Spec or Performance/Custom | OE Spec |
| Adjustable | Yes |
| Features | Sealed |
| Brand | xluxury-autoparts |
| UPC | 688209039979 |
| Manufacturer Part Number | XL805137A01 |
| Interchange Part Number | Air Suspension Spring Bags, Air Ride Spring Bags |
| OE Part Number | LR032570, LR051702, LR032563, LR051700 |
| Superseded Part Number | RNB000070, RNB000750, RNB000060, RNB000740 |
