StopTech Sport Slotted Brake Rotor; Rear Right
Premium e-coated rotor with advanced metallurgy that greatly reduces pad squeal. Especially effective with higher friction European style brake pad compounds. Slotted for increased bite, improved looks and better performance.
Features:
- Cryogenic Treatment Reduces Residual Stress
- Slots Helps Evacuate Gasses/Dust/Heat
- Directional Curve Vane Designs On Selected Apps
- Black E-Coated Non-Friction – Corrosion Protection
- Increased Initial bite and Wet Weather Response
- Superior Resistance To Cracks From Thermal Stress
- Double Disk Ground For Consistent Friction Surface
- Direct OE Replacement
StopTech Slotted Sport Rotors are 1-piece direct replacement brake discs for factory brake systems and stock calipers that look great behind your wheels – and offer significantly improved braking performance. The unique slotting aids with heat and brake dust dispersal, prevents glazing of the pads, adds bite and improves wet and dry braking performance. Built to last, the black e-coating provides protection from corrosion and the high carbon metallurgy (in most applications) offers quieter operation, better crack resistance and increased performance.
| Disc Mounting |
Floating |
| Weight (lbs) |
17.250 |
| Misc Holes |
1 |
| Weight (kgs) |
7.840 |
| Vane Style |
Pillar |
| Hat ID (mm) |
146.900 |
| Hat ID (in) |
5.783 |
| Rotor Type |
Vented |
| Discard Thickness |
20.00 |
| Mounting Bolt Hole Circle Diameter |
112.00 |
| Center Hole Diameter |
2.677 |
| Nominal Thickness |
0.858 |
| Hat Finish |
Coated |
| Nominal Thickness |
21.800 |
| Mounting Bolt Hole Circle Diameter |
4.409 |
| Discard Thickness |
0.787 |
| Stud/Lug Hole Quantity |
5 |
| Stud/Lug Hole Diameter |
15.300 |
| Overall Height |
1.425 |
| Stud/Lug Hole Diameter |
0.602 |
| ABS Tone Ring Included |
No |
| Outside Diameter |
330.00 |
| Outside Diameter |
12.992 |
| Overall Height |
36.200 |
| Center Hole Diameter |
68.00 |
| Surface Type |
Slotted |
Fits these Vehicles: 2017 – 2019 Audi A4, 2017 – 2019 Audi A4 allroad, 2017 – 2019 Audi A4 Quattro, 2016 – 2019 Audi A5, 2018 – 2019 Audi A5 Quattro, 2018 – 2019 Audi A5 Sportback, 2014 – 2019 Audi A6, 2012 – 2019 Audi A6 Quattro, 2016 – 2018 Audi A7, 2011 – 2018 Audi A7 Quattro, 2015 – 2016 Audi A8, 2013 – 2018 Audi A8 Quattro, 2013 – 2019 Audi Q5, 2016 – 2018 Audi Q7, 2010 – 2019 Audi S4, 2011 – 2019 Audi S5, 2018 – 2019 Audi S5 Sportback, 2015 – 2016 Audi S7, 2014 – 2018 Audi SQ5, 2015 – 2020 Porsche Macan
