TrakMotive CV Axle Shaft for 2014-2016 Land Rover LR4 RV-86013
Fitment Chart:
| Years | Make | Model | Notes |
|---|
| 2014-2016 | Land Rover | LR4 | OE AAR design |
Specifications:Part Category: CV Axle Shaft
Brand: TrakMotive
Manufacturer Part Number: RV-86013
Vehicle Position: Front Passenger Side
Placement on Vehicle: Front Right
Label: AAR CV Axle Shaft
Product Type: Factory Replacement
Type: CV Axle Shaft
ABS Ring Tooth Count: 48
ABS Ring Type: Toothed
ABS Tone Ring Included: Yes
Axle Nut Head Type: Hex
Axle Nut Height (in): 7/8
Axle Nut Height (mm): 23
Axle Nut Hex Size (in): 1 3/8
Axle Nut Hex Size (mm): 35.5
Axle Nut Included: Yes
Axle Nut Length (in): 1 5/8
Axle Nut Length (mm): 40.99
Axle Nut Locking Type: Self-lock
Axle Nut Thread Size: M24*2
Inboard Joint Boot Material: Thermoplastic
Inboard Joint Type: Long+male
Inboard Shaft Connection Style: Spline
Number Of Inboard Splines: 29
Number Of Outboard Splines: 29
Outboard Joint Boot Material: Thermoplastic
Outboard Joint Type: Conventional
Outboard Shaft Connection Style: Spline
Overall Compressed Length (in): 39 5/16
Overall Compressed Length (mm): 998
Overall Extended Length (mm): 1055.5
Overall Extended Length(In): 41 9/16
Interchange Part Number: RV-86013
All Interchanges: RV-86013
Brand Label: AAR CV Axle Shaft
Important Information:
- Product Notes - If the product notes states "with" or "without", this means this will fit if your vehicle is equipped "with" or "without" that feature. For example, if it states "with fog lamps", this means your vehicle must be equipped with fog lamps. This does not mean that fog lamps are included.
HOW TO CHECK VEHICLE FITMENT:
Please use eBay Vehicle Compatibility Guide to determine fitment to your vehicle.
- Select your vehicle using the eBay Compatibility Guide
- Important: Hover or click the Notes section to view additional fitment information
RETURN POLICY:
We offer a 30 day return policy on new and unused items in original packaging. Please see the
Returns section of the listing for full return policy information.
Damaged items can only be exchanged once the original shipment is received back.
SHIPPING INFORMATION:This ships via standard shipping.
We ship from multiple warehouses and will always ship from the closest warehouse to your location.
International orders are handled exclusively through the eBay Global Shipping Program.
