Microswitch TACT; SPST; Pos: 2; 0.05A/12VDC; SMT; none; 1.6N; 5mm
PANASONIC
MPN: EVQPNF05M
Body dimensions: 6x3.5x3.5mm
Button height: 5mm
Price per 2 pcs
Technical parameters
| Parameter | Value |
| Actuator colour | black |
| Type of switch | microswitch TACT |
| Contacts configuration | SPST |
| Number of positions | 2 |
| Stable positions number | 1 |
| DC contacts rating @R | 50mA / 12V DC |
| Mounting | SMT |
| Illumination | none |
| Operating Force | 1.6N |
| Body dimensions | 6x3.5x3.5mm |
| Button height | 5mm |
| Switching method | OFF-(ON) |
| Manufacturer series | EVQPN |
| Operating temperature | -30...85°C |
| Button shape | rectangular |
| Leads | for PCB |
| Max. contact resistance: | 100mΩ |
| Min. insulation resistance | 0.1GΩ |
| Mechanical durability | 50000 cycles |
| Kind of package | reel |
Weight: 50 g
