2.6cc Vertical Single Cylinder 4-Stroke OHV Gasoline Engine Internal Combustion
Features:
Mini Engine:
This is a water-cooled vertical single-cylinder engine with a speed limit mechanism and a radiator, crafted from brass and stainless steel with a wooden base for easy placement and handling.
Exquisite Workmanship: The excellent desktop model engine produces exciting sound wave during work for eyecatching charm of the mechanical operation of the engine. It will be appreciated for umcompromising performance.
Engine Start Methods:
1. Check engine circuitry from the wooden base, connect the fuel tank fuel tube, and install 3 AA batteries (4.5V).
2. Fill 95# gasoline into the tank. Rotate the flywheel clockwise on the right side of the engine (the surface of the power switch) for several times to make the mixed fuel enter the cylinder. Make sure that there is no air in the fuel tube.
3. Turn on the power switch, then quickly turn the flywheel clockwise to start the engine on the right side (power switch surface).
Precautions:
1. The engine will not start if the ignition device and the cylinder compression is normal, in that case the carburetor oil needle adjustment is needed.
2.After tightening the main oil needle on the carburetor, loosen the 1/4 ring and start the flywheel to make the mixing ratio of gasoline and air normal.
3.The power switch should be turned off when the machine stops running.
Perfect Model Gift:
The historic vintage engine makes a perfect addition for model enthusiasts and collectors for their spare time and excellent personalized gift for mechanical fans for birthdays and Christmas. Suitable for ages 14 and up.
Specifications:
Material: Brass + Stainless Steel + Wood
Article Number: H73
Engine Dimensions: 11 x 9 x 15.5cm
Engine Weight: 1500g
Package Dimensions: 20 x 20 x 9.8cm
Package Weight: 1950g
Wood Base Size: 15 x 12 x 3cm
Displacement: 2.6cc
Bore: 1.3cm
Stroke: 2cm
Ignition Power Supply Voltage: AA Batteries(Not Included)
Start Method: External Force(Electric Drill) or Hand Pulling
Packing: Box
Package List:
1 x H73 Holt Engine Model
1 x Instructions
