Radiator Configuration:
3 Rows of tubes
Overall Size: 27" Hx 21 6/7"W
Core Size: 18 "Hx 17 5/8"W
Inlet Location Diameter: 1 1/2" Passenger side
Outlet Location Diameter: 1 1/2" Driver side
Transmission Oil Cooler: Included
Transmission Oil Cooler Size:
¢26*305*3/8-18NPT(P)
New radiator cap:Include
Surface: Polished
DPI: 1164
Application:
For 1991-1994 Ford Explorer 4.0L
For
1985-1994 Ford Ranger 2.8L 2.9L 3.0L 4.0L
For
1991-1994 Ford Bronco II 2.8L 2.9L
For
1994 Mazda B4000 4.0L
For
1991-1994 Mazda Navajo 4.0L
Please verify your radiator measurements before ordering
Package include:
New 3 ROW Aluminum Radiator
NOTE: Our shop have a variety of models of separate 2/3/4 row radiator or separate shroud and fan for sale and fan relay kit !
We have warehouses in CA, NJ, GA which can guarantee the fast delivery to any city in United States
How to replace a new radiator
Step 1: Disconnect the battery before proceeding,make sure the car, engine, and coolant are NOT hot!
Step 2: Examine the radiator (or overflow) cap and check the belts and hoses for damaged,
Step 3: Open the petcock valve or remove the bottom radiator hose to drain the coolant. Drain the coolant into a plastic reservoir.
Step 4: With the coolant drained, start removing hoses, clamps and the radiator bolts keeping the radiator in place.
Step 5: With all the hoses, bolts, and lines removed, you should be able to remove the radiator from the vehicle.
Step 6: Set the new radiator in place, and then reattach all the previously removed parts.
Step 7: Check that the petcock is closed and that all other valves and caps on the new radiator are shut.
Step 8: Trapped air in the cooling system,and recheck the coolant level in the reservoir (overflow) tank after the job is completed
