Radiator Size:

High Performance Racing Spec.
3-Row of tubes Core Racing Design
Core Size: 16-3/8" x 17-1/4"
Overall Size: 21-1/2" x 19-5/8"
Upper Inlet is: 1-1/2" (Passenger Side)

Lower Outlet is: 1-3/4" (Passenger Side)

OEM Style Brass Petcock Drain.

CNC Machined Billet and High Pressure Radiator Cap 1.3 Bar

Upgrade Performance

1.Made from Aircraft AA5052 grade aluminum for prolonged lifespanand with raw aluminum finish

2.Brazed core technology to guarantee optimum performance and dependability

3.All AA5052 Aluminum 2mm thick tanks and fittings,Ensure it's hard and durable

4.Billet Aluminum CNC machined fill neck rugged and durable

5.Ergonomic design CNC machined cap with Engraved craftsmanship, anodized treatment.

6.OEM style brass petcock drain much better than other plastic one on eBay

7.Carefully crafted to exceptional OE standards for precise fit.

Vehicle Fitment
1965-1966 Ford Mustang 4.7L 4.3L MT
1960-1965 Ford Falcon 2.4L 2.8L 3.6L 4.3L 4.7L MT
1960-1965 Ford Ranchero 2.4L 2.8L 3.3L 4.3L 4.7L MT
1960-1965 Mercury Comet 2.4L 2.8L 3.3L 4.3L 4.7L MT
Interchange Part Number: CC259 ,EC259 ,AE259 ,MC259,DPI259 ,CUC259

PLS Note ： Only For Manual MT ,Not Include Trans Cooler

DESCRIPTION:

Our Radiator is made of AA5052 aircraft aluminum. Its different from other sellers T-3303 Series. In fact, AA5052 series Aluminum is much better than T-3303 series.

More than 90% of aftermarket manufacturers use the T-3303 series Aluminum, because it is cheaper and easier to get the material. However, T-3303 aluminum has many disadvantages, such as poor polishing effect, softness, easiness to scratch and corrode, poor heat dissipation effect. If the T-3303 aluminum radiator is operated in high pressure and high temperature for a long time, the leaking problem would occur very soon.

AA5052 Aluminum is an Al-Mg alloy with good corrosion resistance, excellent reliability and cold work ability and strength. The main alloying element of AA5052 is magnesium, which has good forming and processing properties. It is widely used in the manufacture of aircraft fuel tanks, oil pipes, and sheet metal parts of transportation vehicles and ships, hardware products, and electrical-appliance casings.

This AA5052 Aluminum Radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This AA5052 Aluminum Radiator is at least 30%-45% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.
