5*DC3.6V-24V 433Mhz 1CH Relay Wireless RF Remote Control Switch Receiver Module
$17
DESCRIPTION
Wireless control LED lamp string, Christmas tree light string, light control switch
·Long range working voltage
·Ultra low power,High sensitive response
Specification:
Working voltage: DC 3.6V~24V
Maximum load: 2A
Static current: 3.6 mA ~ 5.5mA
Working frequency: 433MHz
Reception sensitivity: ≥ -107dBm
Output DC3.6V~DC24V
Size: 22.5 mm x 11mm x 8mm (length × width × high)
Mini size support coding format 1527 learning code
Input: DC3.6V~DC24V
Output: DC3.6V~DC24V
Modulation mode:ASK (superheterodyne)
Appearance size: 22.5mmx 11mm x 8mm (length × width × high)
Number of stored remote controls: ≤ 5
Working mode: Momentary, Toggle, Latching Mode
Learning style: Learning Button
Working temperature: -20 degrees 80 degrees
Package Include:
5pcs * Light Switch Receiver Module
