Product features:
The CH32V003 series is an industrial grade universal microcontroller designed based on the RISC-V2A core, which supports a 48MHz system main frequency in terms of product functionality.
2. Provide commonly used peripheral functions, including 1 set of DMA controllers, 1 set of 10 bit analog-to-digital conversion ADCs, 1 set of operational amplifier comparators, multiple sets of timers, and standard communication interfaces such as USART, I2C, SPI, etc.
3. The rated working voltage of the product is 3.3V or 5V, and the working temperature range is -40 ℃~85 ℃ industrial grade.
4. This series has features such as wide voltage, single line debugging, low power consumption, and ultra small packaging.
5. Small size, but rich peripheral functions, capable of conducting more experiments.
Product parameters:
Rated working voltage: 3.3V or 5V
Working temperature range: -40 ℃~85 ℃ Industrial grade
Peripheral functions: 1 * Type-c interface, 1 * power switch, 1 * reset button, 2 * function switch, 1 * power indicator, 2 * experimental LED light, 1 * download connection, 1 serial port chip, IO full output
Rich routines
1. Basic Routine - ADC Operation
2. Basic Routines - DMA Operations
3. Basic Routine - EXTI Operation
4. Basic Routine - FLASH Operation
5. Basic Routine - TIM Timer Operation
6. Basic Routine - USART Transceiver
7. Basic Routines - I2C Operations
8. Basic Routines - IWDG Operations
9. Advanced Routine - OPA Operation
10. Advanced Routine PWR Operation
11. Advanced Routines - RCC Operations
12. Advanced Routines - SIP Operations
13. Advanced Routines - SRC Operations
14. Advanced Routine - YSTICK Operation
15. Advanced Routines - IAP Operations
16. Advanced Routine GPIO Operation
17. Advanced Routines - TIM Operations
Product Description:
Equipped with a USB to TTL to serial port (which can be used as a regular serial port module), this is very practical and greatly convenient for product debugging. It is commonly used for printing debugging in official processes. The board can be directly connected to a computer using a data cable to use the serial port, and the TXD and RXD pins of the serial chip are also introduced from the board. This way, the board can also be used as a regular serial port module, just turn off the board switch, and the module is now a regular serial port module, One module is used as two modules.
Try to be compatible with official processes and boards as much as possible: In addition to adding additional functions, our board circuits also try to be compatible with official application circuits and processes, which better integrate circuits and processes and are very practical.
Product List:
1X development board
