Centric Rear Disc Brake Rotor for Volvo (320.39043H)
Fitment Chart:
| Years | Make | Model | Drive Type | Notes |
|---|
| 2017-2018 | Volvo | S60 Cross Country | | 316mm Front Disc; Solid Rear Disc |
| 2016 | Volvo | S60 Cross Country | | 315mm Front Disc |
| 2016 | Volvo | S80 | | Solid Rear Disc; Electric Parking Brakes |
| 2015-2018 | Volvo | V60 | | Solid Rear Disc |
| 2015-2018 | Volvo | V60 Cross Country | | Solid Rear Disc |
| 2013-2016 | Volvo | S60 | | 300mm Front Disc |
| 2012-2015 | Volvo | S80 | FWD | 300mm Front Disc |
| 2011-2018 | Volvo | S60 | | Solid Rear Disc |
| 2009-2011 | Volvo | S80 | FWD | 300mm Front Disc; Electric PB |
| 2009-2015 | Volvo | S80 | AWD | 315mm Front Disc |
| 2008 | Volvo | S80 | | Solid Rear Disc; Electric Parking Brake |
| 2008-2010 | Volvo | V70 | | Solid Rear Disc |
| 2008-2016 | Volvo | XC70 | | Solid Rear Disc |
Specifications:Part Category: Disc Brake Rotor
Brand: Centric
Manufacturer Part Number: 320.39043H
Vehicle Position: Rear
Placement on Vehicle: Rear
Label: Centric GCX Elemental Protection Disc Brake Rotors - Full Coating, High Carbon Content
Product Type: Factory Replacement
Type: Disc Brake Rotor
Number of Pieces: 1
Discard Thickness: 0.354
Discard Thickness: 9.000
Nominal Thickness: 0.429
Nominal Thickness: 10.900
Disc Finish: Fully coated
Hat Finish: Coated
Overall Height: 1.610
Overall Height: 40.900
Outside Diameter: 11.850
Outside Diameter: 301.000
ABS Tone Ring Included: No
Surface Type: Smooth
Solid Or Vented Type Rotor: Vented
Bearings Included: No
Center Hole Diameter: 2.504
Center Hole Diameter: 63.600
Mounting Bolt Hole Circle Diameter: 108.000
Mounting Bolt Hole Circle Diameter: 4.252
Stud/Lug Hole Quantity: 5
Stud/Lug Hole Diameter: 0.622
Stud/Lug Hole Diameter: 15.800
Disc Mounting [cntrc]: Floating
Hat ID [cntrc] in: 6.921
Hat ID [cntrc] mm: 175.800
Misc Holes [cntrc]: 1
Weight [cntrc] kgs: 5.160
Weight [cntrc] lbs: 11.350
