Compatibility Vehicle:
2000-2005 Ford Excursion
1999-2004 Ford F-250 Super Duty
1999-2004 Ford F-350 Super Duty
1999-2004 Ford F-450 Super Duty
1999-2004 Ford F53
1999-2004 Ford F-550 Super Duty
About Radiator And Condenser
Radiator:
The radiator is a main part of the cooling system. Coolant flows through the tubes inside the radiator, which are surrounded by fins that direct airflow. When the vehicle is moving down the road, air flows through these fins and cools the coolant. The lower temperature coolant is then sent back to the engine. A failed radiator can lead to engine overheating and potential engine damage.
Images are for structure reference only.
Condenser
The condensers are a critical component of your vehicle’s air conditioning system. The AC condenser transfers heat from the refrigerant to the atmosphere and thus is comparable to your engine’s radiator insofar as function.
Examples of faults that are commonly seen in AC condensers include external damage to fins or tubes, pinhole leaks, and clogged passages. When these occur the condenser usually has to be replaced (save for minor damage to fins which can be straightened with a fin “comb”). so when should i replace my car condenser? 1.Leaking. 2.Air not as cool as it should be. 3.No cool air at all.
Radiator And Condenser Safety Tip
- Check the Radiator's Air Vent/Bleed Valve. Before turning on your radiators, check out the bleed valve or air vent.
- The AC condenser system is under very high pressure, up to several hundred PSI when operating, and thus you can be seriously injured.AC condenser of the replace would be best left to the professionals. Always wear safety glasses when working on your vehicle. Wear other personal protective equipment (PPE) when necessary.
Radiator And Condenser Replace Steps
Radiator:
- Raise and support the vehicle, Open the petcock valve or remove the lower radiator hose to drain the coolant from the radiator.
- Disconnect the radiator reservoir hose, Remove the upper and lower radiator hose.
- Disconnect the cooling fan electrical connector, Remove the cooling fan mounting bolts, Remove the cooling fan.
- Disconnect the transmission cooler lines. Remove the radiator mounting bolts, Remove the condenser mounting bolts, Remove the radiator from the vehicle.
- Mount the radiator. Mount the new radiator in position.
- Install the condenser mounting bolts and tighten them down, Install the radiator mounting bolts.
- Connect the transmission cooler lines, Mount the fan. Mount the cooling fan in position, Install the cooling fan mounting bolts, Reconnect the cooling fan electrical connector.
- Slide the hose onto the connection. Install the upper and lower radiator hose. Connect the radiator reservoir hose. Close the drain petcock as needed. Then fill the radiator with coolant.
- Bleed the air from the cooling system.
Condenser:
- Locate your A/C condenser. Inspect the condenser for cracks that can lead to leaking.
- Recover the refrigerant (Discharge the AC system). This will need to be done with a recovery machine. If the Freon has already leaked out you will not need to do this.
- Remove any grilles, supports, lock braces to gain access to the condenser.
- Remove the condenser's refrigerant lines. Remove the condenser mounting bolts. Remove the condenser.
- Install a new condenser making sure any rubber cushions fit properly on the condenser assembly.
- Pour a small amount of compressor oil into the line fittings. Reconnect the A/C lines. Replace all O-rings. Re-install any parts that were removed in order to gain access to the condenser.
- Evacuate all remaining refrigerant using a specific AC machine that pulls a vacuum on the system. Hold the vacuum for 10 minutes to check for leaks.
- Recharge the A/C system with the recommended type and amount of refrigerant. Each vehicle takes a different amount of refrigerant.
- Test A/C system by measuring the temperature coming out of vents inside the vehicle.
Radiator And Condenser FAQ Anwser
- About shipping: We have two warehouses in US, one is located in CA, and other one is located in GA. We will dispatch packages from the nearest in stock warehouse by recipient's address accordingly. Up to 99% Orders could be shipped within 24 hours after payment completed.
- About incompatibility parts received: Please provide us with detailed vehicle information including Year/ Made/Model/Trim and Engine, or VIN#. With these information, we could try to help to find out a correct OE# part or exchange a right one for you if we have it in stock.
- About damaged package: Please take some photos of the damage part and send to us, we will inspect it carefully and confirm with engineer if the damage will cause functional or installation issues or not. For serious damage radiator, we could do resend a new one or issue refund as compensation.
- About shipping method: UPS, FedEx, USPS are available here and we will choose one of them according to the part you order, for generally speaking, the delivery time is about 3 to 8 working days.
- Why choose us: Professional auto parts seller, Premium Quality Products, Excellent service, Satisfactory shopping experience.
- Other questions: Please message us before order.
| Item Specifics | |
|---|---|
| Brand | Autocoolinghome |
| Manufacturer Part Number | Co83792102 |
| Condition | New |
| Warranty | 1 Year |
| Interchange Part Number | Radiator For Ford F-250 Super Duty Ford F-350 Super Duty |
| Other Part Number | Radiator and Condenser,air condenser,condenser in ac |
| Superseded Part Number | Aluminmu radiator,AC Condenser,Cooling Radiator & AC Condenser |
| Custom Bundle | YES |
| Fitment Type | Direct Replacement |
| Material | Plastic Tank with Aluminum Core |
| Placement on Vehicle | Front |
| Applicable Regions | US |
| Type | Car Radiator,Car AC Condenser |
| Radiator Core Height | 21.46ln./545mm |
| Radiator Core Width | 21.34ln./542mm |
| Radiator Core Thicknes | 0.63ln./16mm |
| Condenser Core Height | 17.13ln./435mm |
| Condenser Core Width | 29.85ln./758mm |
| Condenser Core Thicknes | 0.63ln./16mm |
| Radiator Cap | As picture |
| Color | Black and Silver |
| Notes | Please verify the item fits your vehicle or not by compatibility |
| Color | Black or Silver |
| Notes | Please verify the item fits your vehicle or not by compatibility |
| Notes | Radiator&Condenser will be shipped out separately |
