DT-9939
Waterproof Industrial Wireless USB RMS Multimeter with Capacitance Frequency Duty Cycle
DT-9939
Waterproof Industrial Wireless USB RMS Multimeter with Capacitance Frequency
Duty Cycle NEW!!
Click
image to enlarge
|
This
is a brand new DT-9939  certified
industrial true RMS digital multimeter from Ruby Electronics.
DT-9939 provides safe measurements with double molded plastic housing
design and IP67 waterproof function. DT-9939 performs datalogger &
True RMS AC voltage and current measurements, 40,000 counts resolution
and a 0.06% basic DC accuracy. The large LCD display with analog
bargraph and backlit ensure that readings are easy to read under all
circumstances. All inputs are protected to EN 610101-1 CATIV 600V/CATIII
1000V.
This
device with the included software allows the data to be stored and
recalled wirelessly to/from a Windows PC. Proper use and care of
this meter will provide many years of reliable services.
Safety
Conformance: EN61010-1 CAT IV 600V, CAT III 1000V 1000V input protection
on all ranges 10A/1000V & 0.5A/1000V fuses
|
|
Function
|
Range
|
Resolution
|
Accuracy
|
|
DC Voltage
|
400mV
|
0.01mV
|
±(0.06%
reading + 4digits)
|
|
4V
|
0.0001V
|
|
40V
|
0.001V
|
|
400V
|
0.01V
|
|
1000V
|
0.1V
|
±(0.1%
reading+ 3 digits)
|
|
AC Voltage
(AC+DC)
50 to 1000Hz
|
400mV
|
0.01mV
|
±(1.0%
reading + 40digits)
|
|
4V
|
0.0001V
|
±(1.0%
reading + 30 digits)
|
|
40V
|
0.001V
|
|
400V
|
0.01V
|
|
1000V
|
0.1V
|
|
All AC voltage
ranges are specified from 5% of range to 100% of range
|
|
DC Current
|
400μA
|
0.01μA
|
±(1.0%
reading + 3 digits)
|
|
4000μA
|
0.1μA
|
|
|
40mA
|
0.001mA
|
|
|
400mA
|
0.01mA
|
|
|
10A
|
0.001A
|
|
|
(20A:30 sec
max with reduced accuracy)
|
|
AC Current
(AC+DC)
50 to 1000Hz
|
400μA
|
0.01μA
|
±(1.0%
reading + 3 digits)
|
|
4000μA
|
0.1μA
|
|
|
40mA
|
0.001mA
|
|
|
400mA
|
0.01mA
|
|
|
10A
|
0.001A
|
|
|
(20A: 30 sec
max with reduced accuracy)
|
|
All AC voltage
ranges are specified from 5% of range to 100% of range
|
NOTE:
1. Accuracy is stated at 18°C to 28°C (65°F
to 83°F) and less than 75%RH.
2. AC switch according to the calibration of
sine wave. It generally increase ±(2% reading + 2% full scale) if non
sine wave in the wave crest less than 3.0.
|
Function
|
Range
|
Resolution
|
Accuracy
|
|
Resistance
|
400Ω
|
0.01Ω
|
±(0.3%
reading + 9 digits)
|
|
4k Ω
|
0.0001kΩ
|
±(0.3%
reading + 4 digits)
|
|
40k
|
0.001kΩ
|
|
400kΩ
|
0.01kΩ
|
|
4MΩ
|
0.001MΩ
|
|
40MΩ
|
0.001MΩ
|
±(2.0%
reading + 10 digits)
|
|
Capacitance
|
40nF
|
0.001nF
|
±(3.5%
reading + 40 digits)
|
|
400nF
|
0.01nF
|
|
4μF
|
0.0001μF
|
±(3.5%
reading + 10 digits)
|
|
40μF
|
0.001μF
|
|
400μF
|
0.01μF
|
|
4000μF
|
0.1μF
|
±(5% reading
+ 10 digits)
|
|
40mF
|
0.001mF
|
|
Frequency
(electronic)
|
40Hz
|
0.001Hz
|
±(0.1%
reading + 1 digits)
|
|
400Hz
|
0.01Hz
|
|
4kHz
|
0.0001kHz
|
|
40kHz
|
0.001kHz
|
|
400kHz
|
0.01kHz
|
|
4MHz
|
0.0001MHz
|
|
40MHz
|
0.001MHz
|
|
100MHz
|
0.01MHz
|
Not specified
|
|
Sensitivity:
0.8V rms min.@ 20% to 80% duty cycle and <100kHz; 5Vrms min
@ 20% to 80% duty cycle and > 100kHz.
|
|
Frequency(electricaI)
|
40.00HZ-10kHz
|
0.01Hz-0.001kHz |
±(0.5%
reading) |
|
Sensitivity:1Vrms
|
|
Duty Cycle
|
0.1 to 99.90%
|
0.01%
|
±(1.2%
reading + 2 digits)
|
|
Pulse width:
100 us - 100 ms,Frequency: 5Hz to 150kHz
|
|
Temperature(type-K)
|
-50 to 1200°C
|
0.1°C
|
±(1.0%
reading + 2.5°C)
|
|
-58 to 2192°F
|
0.1°F
|
±(1.0%
reading + 4.5°F)
|
|
|
(probe
accuracy not included)
|
|
4-20mA%
|
-25 to 125%
|
0.01%
|
±50 digits
|
|
0mA=-25%,
4mA=0%, 20mA=100%, 24mA=125%
|
Note: Accuracy
specifications consist of two elements:
• (%reading)- This is the accuracy of the
measurement circuit.
• (+ digits)-
This is the accuracy of the analog to digital converter.
|
|
Accessories: Test leads, 9V battery, Type K temperature
probe, gift box with carrying case. USB cable and Software
