Delphi Fuel Pump Module Assembly for Astro, Safari FG0068
Fitment Chart:
| Years | Make | Model | Notes |
|---|
| 1997-1999 | GMC | Safari | with Original OE design had a 2x2 connector, OE design upgraded to a 1x4 Connector; with A 1x4 splice kit included for vehicles with 2x2 Connector; Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, itâs recommended to clean the fuel tank before installing a new pump.; Use of fuel tank cleaning kit FC01 is recommended. |
| 1997-1999 | Chevrolet | Astro | with Original OE design had a 2x2 connector, OE design upgraded to a 1x4 Connector; with A 1x4 splice kit included for vehicles with 2x2 Connector; Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, itâs recommended to clean the fuel tank before installing a new pump.; Use of fuel tank cleaning kit FC01 is recommended. |
Specifications:Part Category: Fuel Pump Module Assembly
Brand: Delphi
Manufacturer Part Number: FG0068
Product Type: Factory Replacement
Type: Fuel Pump Module Assembly
Number of Pieces: 1
Outlet Outside Diameter: 0.375
Voltage: 13.0
Fuel Type: Gas
Regulator Included: No
Maximum Pressure: 109.0
Terminal Type: Blade
Gasket Or Seal Included: Yes
Terminal Quantity: 4
Lock Ring Included: No
Terminal Gender: Male
Strainer Included: Yes
Inlet Type: Strainer
Outlet Type: Quick connect
Outlet Quantity: 3
In Tank or External: In tank
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Internal Or External Strainer: Internal
Average Current Draw: 10
Average Flow Rating: 24
Pump Type: Electric
Fuel Level Sender Assembly Included: Yes
Item Grade: Standard replacement
Package Contents: Fuel pump module assembly w/float arm, seal, splices, wire harne
System Pressure: 62 psi
Vapor Pressure Sensor: Yes
Interchange Part Number: 150009 19180091 19331282 19369961 1AMFP00098 25178736 25314776
Replaces Part Numbers: 2630301 67072 953-0013 953-5033 A27006 A30027 AFS0530S D5331018
Replacement Part Numbers: E3940M EFG0068 M319673 MPA27006 MPA30027 MU109 MU1782 P74752M
Replace Part Numbers: RE0530S SP413M
