Features:
*Fixed turn lamp current is 0.1 times the current value ( Used to identify whether the battery is fully charged When charging).
*Made from a dedicated for IC and high- for precision current sensing resistor, proving a more stable constant current, (when 20° to 100° constant current 1A, temperature drift less than 1%). Particularly suitable for driver.
*High output current, the max output current can reach 12A.
*Four high frequency capacitance, can lower output ripple, enhance the work stabilization.

Specifications:
Module Properties: non-isolated step-down constant current, constant voltage module (CC ) charging module
Input voltage: DC 7-32V
Output voltage:DC 0.8-28V continuously adjustable
Output Current: 9A 12A (when power tube\'s temperature exceeds 65 degrees, please add cooling fan)
Constant current range: 0.2-12A ( adjustable )
Turn lamp current: constant current value * ( 0.1 ) , turn the lamp current and constant value linkage, such as constant current value is 3A, turn the lamp current is set to a constant current is 0.1 times (0.1 * 3A = 0.3A).
Lowest pressure: 1V
Output Power: Maximum power is about 300W
Conversion efficiency: up to about 95%
Operating frequency: 300KHZ
Output ripple: 20M bandwidth
Input 24V Output 12V 5A ripple around 50mV (Excluding noise)
Output short circuit for Protection : Yes, constant current
Input Reverse Polarity for Protection: None
Output prevent backflow: None
Wiring: Terminal
No-load current: Typical 20mA (24V switch 12V)
Load regulation: ± 1% ( constant )
Voltage regulation: ± 1%
for Dynamic for response speed: 5% 200uS
Potentiometer adjustment direction: clockwise (increase) , counterclockwise (decrease). the potentiometer() closed to the input voltage is used to regulate voltage, the potentiometer(CC) closed to output voltage is used to regulate current (CC)
Operating temperature: Industrial grade (-40 °c to +85 °c) ( please note the actual use of the power tube temperature , high temperature heat strengthened please )
Indicator: dual color indicator, charging indicator light is red, the green light means fully charged ( No load is green )

Package Contents:
1 Pcs Converter Module
