Product Description
This replacement window regulator is precision-engineered and extensively tested to match the exact fit, function and performance of the stock window regulator on specific vehicle years, makes and models.
Trustworthy replacement - engineered and tested to match the fit, function and performance of the original window regulator on specified vehicles.
Quality assured - extensively tested by cycling thousands of times in an actual vehicle door to ensure a long, trouble-free service life.
Easy installation - reverse-engineered to match the original equipment shape and dimensions to provide a direct, seamless fit.
Tech Tips
Use painter’s tape rather than duct tape to secure window. It is less likely to damage paint or leave sticky residue.
A plastic pry tool is useful. It will not easily damage delicate trim like a screwdriver or metal pry bar.
The replacement regulator should have a liberal amount of grease on slide area. If there is not much grease present, white lithium grease works well to lubricate the slide area.
Window run channels should be cleaned and lubricated before installation of a new window regulator assembly. Silicone spray works well.
Removal Instructions
STEP 1: Using a Phillips head screw driver or Torx bit set, remove the interior door trim panel retaining screws/Torx bits.
STEP 2: Remove the interior door handle screws/Torx bits, and remove the interior door handle.
STEP 3: Remove the power switch assembly and disconnect the power switch harness.
STEP 4: Using an interior trim removal tool, remove the interior door trim panel.
STEP 5: Temporarily connect the power switch assembly to lower the door glass,exposing the screws attaching the door glass to the window regulator.
STEP 6: Remove the screws attaching the door glass to the window regulator. Once the screws have been removed, manually slide the door glass into the closed position, and hold in place with either painter’s tape, a wedge, or a suction cup saddle assembly.
Items Description
Attachment Type:Bolt On
Material:Metal and Plastic
Fitment:Direct Replacement
| Item Specifics | |
|---|---|
| Brand | kintop_coilparts |
| Manufacturer Part Number | KT15009301p |
| Placement on Vehicle | Rear Left |
| Type | Regulator & Motor Assembly |
| Operating Mode | Electric |
| Motor Included | Yes |
| OE/OEM Part Number | 741-390 |
| Custom Bundle | No |
| Package Contents | 1 Power Window Regulator |
| Packaging Type | Box |
| Manufacturer Warranty | 1 Year |
| Fit for | 2007-2014 Cadillac Escalade |
| Superseded Part Number | Rear Driver Left Side Replacements |
| Surface Finish | Smooth |
| Product Fit | Direct fit |
| Attachment Type | :Bolt On |
| Performance Part | Yes |
| Modified Item | No |
| Installation Instructions Included | No |
| Gear Material | Plastic |
| Frame Material | Metal and Plastic |
| Mounting Hardware Included | No |
| Fitment Type | Direct Replacement |
| Weight | about 5 lbs |
| Package Size | 18*10*3 inch |
| Fitment(Note) | Verify this part fits your vehicle using the compatibility chart |
| Housing Material | Steel |
