Features: Improved Transmission: The M20 short IP68 metal CAT6 water-resistant and dust-resistant RJ45 port ensures consistent transfer with a shielded structure, suitable for industrial and outdoor use.
Constructed with plastic PA66 (UL94V-0) housing and metal contacts, it offering excellent durability and resistance to harsh conditions.
IP68 Water-resistant Feature: Fit with a silicone rubber seal for effective defense against moisture and contaminants, meeting IP68 standards for demanding applications.
Easy Installation: easy installation not need soldering or tools, making it quick and straightforward to install with standard RJ45 port.
Wide Compatibility: Supports CAT6 transmission rates for fast Ethernet, works with CAT5/5e/6 cables, ensuring various use.

Specifications: Connector: RJ45 Number of cores 8pins
Component: Housing: PA66 (UL94V-0),
Contact pin 0.5mm diameter coppered wire,
Waterproof: IP68
Flame retardant grade: Flame retardant grade: UL94V-0
Connector wiring ranges: Outer diameter 3~8mm:
Housing wall thickness Thread type more than 3mm, through-hole type: 0.3～5mm
Installation size M20
Connector Transmission Category: CAT6 CAT6 Transmission Speed ​​Ranges Applicable to Gigabit and TenGbit Ethernet Speeds
Voltages: 250V
Insulation resistance: more than 500MΩ
Contact resistance: less than 10MΩ
Size：about 8.2x2.7cm/3.23x1.06in

Package Includes: 1PC Connector

note: Please allow 1-2cm errors due to manual measurement.
Please allow for slight color differences due to different display resolution
