NEW Alarm.com Tyco ADC-620T-LTE Cellular Module for DSC Neo Control Panel Z-Wave

ejc-online

$29

CONTACT SELLER SEE ON EBAY

ejc-online

$29

DESCRIPTION

This listing includes the following:

One (1) ADC-620T-LTE Cellular Module for DSC Neo Control Panel with Z-Wave

Brand: Alarm.com (Made by Tyco Security)
Condition:

BRAND NEW!
Module is in the original, factory plastic packaging - NEVER OPENED - NEVER USED!
These modules are exactly as pictured (IMEI numbers will be different for each unit) - there is no housing or any other parts or accessories - just the add-on module ONLY.
Proper application, installation, and compatibility is the responsibility of the buyer - we cannot offer any technical support or advice.
Each board includes an installed Telit Communications LE910C1-AP Module, as seen in the photos, which supports 4G LTE Band 1, 3, 5, 8, 28, with a target market of Asia Pacific, Australia, New Zealand (Telstra/Vodafone AU) - but again, application and usage is the responsibility of the buyer.
BULK QUANTITIES AVAILABLE.

Free Shipping in the continental US!
In-Stock! Ships within ONE BUSINESS DAY of payment!
US Seller!

Please contact us with any questions.

Thank you,

EJC Ventures, LLC

Alarm.com ADC-620T Details:

The Alarm.com ADC-620T Module for DSC Panels is a add-on module that attaches inside of a DSC security panel. It communicates between the security panel and the Alarm.com cloud service via a cellular network. A user is able to remotely control the security panel and its associated Alarm.com Interactive Services (including Z-Wave devices) via a web application or mobile app.

The ADC-620T Module for Neo enables wireless reporting of all alarms and other system events from the DSC Neo control panel using an all-digital, cellular network (if available) or broadband connection (if available). The module can be used as the primary communication path for all alarm signaling, or as a backup to a telephone connection to the central monitoring station. The wireless alarm signaling and routing service is operated by Alarm.com. The ADC-620T Module also features integrated support for Alarm.com’s emPower solution with built-in Z-Wave capabilities. The ADC-620T Module is compatible with DSC Neo panels with software versions 1.3 and later.

The Alarm.com ADC-620T supports the following command classes:

• Application Status Command Class, Version 1

• Association Command Class, Version 2

• Association Group Information Command Class, Version 1

• Controller Replication Command Class, Version 1

• CRC-16 Encapsulation Command Class, Version 1

• Device Reset Locally Command Class, Version 1

• Manufacturer Specific Command Class, Version 1

• Powerlevel Command Class, Version 1

• Security Command Class, Version 1

• Version Command Class, Version 2

• Z-Wave Plus Info Command Class, Version 2

The Alarm.com ADC-620T controls the following command classes:

• Alarm Command Class, Version 1

• Association Command Class, Version 2

• Association Group Information Command Class, Version 1

• Basic Command Class, Version 1

• Battery Command Class, Version 1

• Binary Sensor Command Class, Version 1

• Binary Switch Command Class, Version 1

• Clock Command Class, Version 1

• Configuration Command Class, Version 1

• CRC-16 Encapsulation Command Class, Version 1

• Device Reset Locally Command Class, Version 1

• Door Lock Command Class, Version 1

• Firmware Update Meta Data Command Class, Version 1

• Manufacturer Specific Command Class, Version 1

• Meter Command Class, Version 1

• Multi Channel Command Class, Version 4

• Multi Channel Association Command Class, Version 3

• Multilevel Sensor Command Class, Version 1

• Multilevel Switch Command Class, Version 1

• No Operation Command Class, Version 1

• Notification Command Class, Version 3

• Powerlevel Command Class, Version 1

• Schedule Entry Lock Command Class, Version 3

• Security Command Class, Version 1

• Thermostat Fan Mode Command Class, Version 1

• Thermostat Fan State Command Class, Version 1

• Thermostat Mode Command Class, Version 1

• Thermostat Operating State Command Class, Version 1

• Thermostat Setback Command Class, Version 1

• Thermostat Setpoint Command Class, Version 1

• Time Parameters Command Class, Version 1

• User Code Command Class, Version 1

• Version Command Class, Version 2

• Wake Up Command Class, Version 2

• Z-Wave Plus Info Command Class, Version 2

This product can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers and/or other applications. All non-battery operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.

Telit LE910C1-AP LTE Cat.1 Module Details:

Telit LE910C1-AP belongs to Telit LE910C1 Series and it's an LTE Cat.1 module supporting download speed to 10Mbps and upload speed to 5Mbps. Telit LE910C1-AP is compliant with the 3GPP Release 10 in s compact LGA form factor.

Telit LTE Cat.1 Module Specs:

* Target market: APAC/ANZ (Telstra/Vodafone AU)

* Support 4G Bands(MHz): B1(2100), B3(1800), B5(850), B8(900), B28(700)

* Support 3G Bands(MHz): B1(2100), B5(850), B8(900)

* Support 2G Bands(MHz): NO

* LTE Cat.1 data rate: Uplink up to 5 Mbps, Downlink up to 10 Mbps

* DC-HSPA+ Download speed to 42Mbps

* LTE FDD Cat.1, 3GPP release 10 compliant

* Rx Diversity and MIMO DL 2x2

* Single Rx option

* VoLTE support

* SMS over IMS

* Built in UDP/TCP/FTP/SMTP stack

* IPv4/IPv6 stack

* Control via AT commands according to 3GPP TS 27.005, 27.007 and Telit Custom AT commands

* SIM application Tool Kit 3GPP TS 51.014

* OMA-DM Telit Software Management

* Simultaneous support of GPS, Glonass, Bei-dou, Galileo, QZSS

* Dimensions 28.2 x 28.2 x 2.2 mm

* Temperature Range: -40°C to +85°C

* REACH and RoHS compliant

* Interfaces

- 181-pin LGA Interface

- 10 I/O ports (@1.8V) including multifunctional I/Os

- USB 2.0 HS / HSIC

- UART

- SPI

- PCM

- 1.8 V / 3 V SIM interface

- RF pad, RX Div. & MIMO pad

* Electrical & Sensitivity

- Output power: Class 3 (0.2 W, 23 dBm) @ LTE

- Supply voltage: Nominal: 3.8 VDC/ Range: 3.3 - 4.2 VDC

* Approvals

- FCC /IC, PTCRB , (North America)

- RCM (Australia)
