Certification: MID Certified

Type: Three-phase Direct 100A high-precision kWh meter. Class .1 accuracy with RS485 MODBUS RTU: baud rate, modbus ID, parity, Bi-directional, import/export, instant volt, amp, power factor, frequency, active power, reactive power, apparent power, industrial control, AMR compatible. Memory Backup. Meter displays if power fails, TOU, up to four tariffs, summertime switch. Fully programmable.

Housing: 7 DIN module case

Usage: Suitable for industrial/commercial sub-billing, FIT/ROC, renewables, solar PV

Current Rating: 100A

Voltage: 230V AC 50/60Hz

Pulse Rate: 400 imp/kWh

Output: Isolated pulsed output and IR

Display: LCD Backlit display, voltage, ampere, kW, PF, Hz, + kWh, -kWh, total kWh

Max Cable Size: 25mm

We always aim to despatch UK orders same day
