Product Features:
It accepts a wide range of DC input from 18v to 60v via Passive PoE (not 802.3af/at PoE) to output fixed 12v/2A via the DC Jack (5.5 x 2.1mm) and 10/100 RJ45 Jack.
This way a non PoE enabled device can be powered remotely via any Passive PoE Injector or Passive PoE Switch.
Notice:
1. it is only compatible with Passive POE switch/Injector which use Mode B(RJ45 Power PIN:4/5+ & 7/8-), it is not compatible with POE Mode A (RJ45 Power PIN:1/2+ & 3/6-).
2. The DC Buck passive PoE Splitter. with following function:
1,Transfer the data signal input from RJ45 socket 1236pins via the other side RJ45 connector to the IP camera.
2,Transfering the DC18-60V power input from RJ45 socket 4578pins(45+, 78-) which the voltage will be lowered to 12V,then through the other side DC port(5.5 x 2.1 mm) into the IP camera.
Product Specifications
Material: Plastic/High-quality oxygen-free copper Cable
Power Pin: 4/5(+) , 7/8(-)
Data Pin: 1/2 , 3/6
Operating Temperature: -10oC ~ +60oC
Storage Temperature: -20oC ~ +70oC
Humidity: Up to 90%
Input Voltage: DC 18-60V
Output Voltage: DC 12V 1.2A
DC Connector Type: 5.5mm x 2.1mm
Ethernet Cable Connector: RJ-45
Ethernet Data rate: 10/100 Mbp
Ethernet Cable: TIA/EIA 568 Cat.5
Transmission Distance: 120 Meters / 394ft
Total Length: 210mm / 8.27 inch
Length: 240mm total length (including connectors)
Weight: 58g
Payment Method
We only accept PayPal
Shipping/Return/Warranty
Shipping Information
We usually ship the items within 1-2 business days after your payment.
After the item has been shipped, I will post a tracking number.
This item is shipped to only U.S domestic, not international. We are located in MA
Return Information
You can return the item within 15 days, The day starts counting after you received the item based on the shipping service. shipping charge is not refundable. Also, return can be only accepted with original box.
The returned item must be 100% resalable condition which includes all original accessories.
You are responsible for shipping cost. You must use UPS or USPS that provide a tracking number.
If there is any physical damage found after we get the item back such as scratches, dent..etc, no money will be refunded.
Please contact us first before you return, RMA number must be provided before you return the item.
Warranty Information
We provide one (1) year warranty on all our products. The warranty only covers defective product. We do not cover the damage caused by the user.
Package Includes
1 x pair of POE Injector Splitter
Other Stuff
Feel free to ask any questions about the product through Ebay messages, I will try my best to answer your question.
