Product Description:
- xluxury-autoparts new rear strut for the 05-09 Land Rover LR3, 10-16 LR4, 2006-2013 Range Rover Sport is new and not remanufactured. xluxury-autoparts features a new custom-made and tuned shock absorber and is assembled with a multi-ply air spring bladder manufactured by ContiTech. The strut assembly also features heavy duty crimping rings, new seals, air fitting and dust cover.
- ContiTech Multi-Ply Air Bladder
- Replace in Pairs
Application:
Range Rover Sport
Excludes VDS Model With Electrical Plug on Mounting Base 2010-2014
GT Limited Edition 3 Sport Utility 4-Door 5.0L 2012
GT Limited Edition Sport Utility 4-Door 5.0L 2011 2013
HSE Lux Sport Utility 4-Door 5.0L 2012-2013
HSE Sport Utility 4-Door 4.4L 2006-2009
HSE Sport Utility 4-Door 5.0L 2010-2013
LE Sport Utility 4-Door 4.2L 2008
Supercharged Sport Utility 4-Door 4.2L 2006-2009
Land Rover LR4
Base Sport Utility 4-Door 3.0L 2014-2016
Base Sport Utility 4-Door 5.0L 2011-2013
HSE Lux Sport Utility 4-Door 3.0L 2014-2016
HSE Lux Sport Utility 4-Door 5.0L 2012-2013
HSE Sport Utility 4-Door 3.0L 2014-2016
HSE Sport Utility 4-Door 5.0L 2010-2013
SE Sport Utility 4-Door 5.0L 2010-2013
V8 Sport Utility 4-Door 5.0L 2010
Land Rover LR3
Base Sport Utility 4-Door 4.0L 2006
HSE Lux Sport Utility 4-Door 4.4L 2009
HSE Sport Utility 4-Door 4.4L 2005-2009
SE Sport Utility 4-Door 4.0L 2005-2009
SE Sport Utility 4-Door 4.4L 2005-2009
OE Number:
LR016418,LR032650,
LR038096,LR041110,
RPD501020,RPD501100
Generation & Evolution:
Land Rover Discovery
First generation (Project Jay; 1989-1998)
Second generation (LR2/L318; 1998-2004)
Third generation (LR3/L319; 2004-2009)
Fourth generation (LR4/L319; 2009-2016)
Fifth generation (L462; 2017-present)
Range Rover Sport
First generation (L320; 2005-2013)
Second generation (L494; 2013-present)
SVR (2015 Pre-Facelift)
SVR (2018 Facelift)
Platform Drive Layout
Front Engine-Four Wheel Drive Layout
Signs that your air suspension needs to be replaced include:
1.Abnormal Sounds
2.Poor Handling Stability
3.Air Leakage
4.Car Body Slant
5.Irregular Tire Wear
6.Over Bend
Note Before Installation:
1.To avoid the possibility of short circuits while working with electric components consult your owner's manual on how to disconnect your battery.
2.Consult your vehicle owner's manual, service manual, or car dealer for the correct jacking points on your vehicle and for additional care, safety and maintenance instructions. Under no circumstances should any work be completed underneath the vehicle if it is not adequately supported, as serious injuries and death can occur.
Removal Guideline:
Caution: Damage to the vehicle and air suspension system can be incurred if work is carried out in a manner other than specified in the instructions or in a different sequence.
1.To avoid the possibility of short circuits while working with electric components consult your owner's manual on how to disconnect your battery.
2.Consult your vehicle owner's manual, service manual, or car dealer for the correct jacking points on your vehicle and for additional care, safety and maintenance instructions. Under no circumstances should any work be completed underneath the vehicle if it is not adequately supported, as serious injuries and death can occur.
1.Remove rear wheel to expose the rear air strut.(picture 1)
2.Loosen and remove the lower mount nut. Support the air strut and remove the lower mount bolt.(pictures 2,3)
3.Loosen and remove the three(3)top mounting nuts.(picture 4)
4.Carefully lower the air strut to gain access to the air line. Unthread the air fitting.(picture 5)
5.Remove the air strut from the vehicle.(picture 6)
6.Remove the air line fitting from the air hose and discard. To remove the air line fitting,remove the collet and the remaining fitting will slide off of air hose.(picture 7)
7.Removal complete.
Installation Guideline:
Installation is in reverse order of air spring removal, with the exception of the Secured reservoir hose.
Highlight:
- This air suspension strut Set fits for Land Rover LR3 LR4 L319 Discovery 2005-2016 Range Rover Sport 2006-2013 Excludes Range Rover Sport VDS Model With Electrical Plug on Mounting Base 2010-2013.
- this air strut replaces the original equipment strut on specified vehicle applications to restore ride quality
- In the areas of safety, accuracy, durability and quality, this product is similar to the original spare part.
- The air suspension can compress the air in a elastic closed container so that it can work effectively.
- It also features in ideal nonlinear elasticity.
- When added altitude controller in the air suspension strut, the height of car can change with load.This air suspension strut is constructed with high quality material, you can use it for a long time.
- xlux’s meticulous component inspection and in-house crimping and testing of every air suspensiion strut ensure a product of unmatched quality and reliability.
- We guarantee that our air suspension strut match or surpass the quality of the original equipment, providing you with confidence in your purchase.
Package Included:
Single for Rear Left or Right Air Suspension Shock Strut
Note:
1.Please double confim the compatibility as well as the OEM number before purchasing.
2.Instruction is not included. Professional installation is recommended
3.Please feel free to contact us for whatever we can help via eBay message; every message will be replied in 12 hours.
| Item Specifics | |
|---|---|
| Placement on Vehicle | Left Right Rear |
| Type | Air Suspension Strut |
| Fitment Type | Direct Replacement |
| Size | Single Dimension(CM) 74.00(Length)*20.00(Width)*19.50(Height) |
| Single Weight(KG) | 9.500 |
| Maximum Operating Pressure (psi) | 195 |
| Minimum Operating Pressure (psi) | 90 |
| Upper Mount Type | Stud |
| Lower Mount Type | Eyelet |
| Included Hardware | None |
| Drive Layout | Front Engine 4WD |
| Platform | LR3 LR4 L320 |
| Custom Bundle | No |
| Material | Iron Aluminium Alloy Rubber |
| Quantity | Single |
| Manufacturer Warranty | 1 Year |
| OE Spec or Performance/Custom | OE Spec |
| Adjustable | Yes |
| Features | Sealed |
| Brand | xluxury-autoparts |
| Manufacturer Part Number | XL110597A01 |
| Interchange Part Number | Air Suspension Shock Strut, Air Ride Shock Strut |
| OE/OEM Part Number | LR016418, LR032650, LR038096, LR041110 |
| Superseded Part Number | RPD501020, RPD501100 |
| Surface Finish | Rust Protected |
| Adjustable Damping | No |
| Air Ride Suspension | Yes |
| Air Adjustable | Yes |
| Gas Charged Shock | Yes |
| Shock Absorber Type | Gas |
| Body End Measuring Point | Center Eye |
| Boot Color | Black |
| Internal Damper Type | Hydraulic |
| Lower Mounting Isolator Included | No |
| New Or Remanufactured | New |
| Shock Absorber Rod End Measuring Point | Shoulder of Stud |
| Progressive Spring Rate | Yes |
| Spring Isolators Included | Yes |
| Spring Rate Type | Progressive |
| Spring Seat Included | No |
| Grade Type | Standard Replacement |
| Package Contents | 1 piece (Rear for left or right) Air Suspension Strut |
| Upper Mounting Isolator Included | yes |
| Shock Absorber System | Double Pipe |
