Features:
*Multifunctional Digital Delay Timer Control Switch: This relay module allows for continuous adjustment of the timing range from 0.1 seconds to 999 minutes, providing for versatile timing options for various applications.
*Reliable and Noiseless : The relay module features noiseless and for spark-free conducting and cutting processes, minimizing electromagnetic interference. It also offers a longer lifespan compared to electromagnetic relay products.
*Powerful and Convenient: Equipped with dual-MOS parallel drive, the module offers lower resistance, higher current, and stronger power. It can handle a wide range of devices such as motors, lights, , micro-pumps, and solenoid valves, making it highly for versatile and convenient.
*Wide Voltage Input and Clear Interface: With a voltage input range of 5-36V, the module can be easily used with many devices. The interface is clear, simple, and easy to understand, meeting almost all your needs.
*Enhanced for protection and Parameter Settings: The module features reverse polarity for protection to prevent damage. It also includes sleep mode and parameter saving capabilities. Even after power-down, all parameter settings remain , convenience and reliability.
Specifications:
*Product Name: Relay Module
*Material: Electronic component
*Size: 6.0*3.4*1.2cm
*Color: As shown
*Operating mode:
P1: trigger signal, the relay is on "OP" time, and then disconnect; in the "OP" time, as follows:
P1.1: signal is triggered again, invalid
P1.2: signal is triggered again, the clock is reset
P1.3: Signal trigger again, relay off, stop the clock;
P-2: trigger signal, the relay off "CL" of time, the relay on "OP" time, and then disconnect relay;
P3.1: trigger signal, the relay is turned on after the "OP" time, the relay off "CL" time, then the cycle, if the trigger signal period, the relay off, stop the clock; the number of cycles ( "LOP ") can be set.
P3.2: without triggering signal, the relay is on "OP" time, the relay off "CL" time, and has been cycling; frequency ( "LOP") cycle can be set;
P-4: signal holding function. If there is a trigger signal timing is cleared, the relay remains on; when the signal disappears, after the timing "OP" time, the relay is; if another signal during timing, timing is cleared;
*Operating voltage: 5--36V.
*Trigger Source: Active-high (3.0V-24V)
*Output capacity: DC 5V - 36V
*Quiescent Current: 20mA; Operating Current: 50mA
*Working temperature: -40-85 °
Package Content:
1*Relay Module
Note:
1. The real color of the item may be slightly different from the pictures shown on website caused by many factors such as brightness of your monitor and light brightness.
2. Please allow slight manual measurement deviation for the data.
