TARAMPS TS 800X4 - 2 OHMS 800 WATTS RMS
We know that the demand for amplifiers that serve Players and Original Multimedia has grown every day. With that in mind, we created the new TS 800×4 2 Ohms with Wire input with 4 individual channels and automatic activation. Characteristic that makes it ideal for this type of application, dispensing with the use of adapters.
With 800 watts of power distributed in 4 channels and the possibility of connecting in Bridge, it can be used with the most varied models of speakers, drivers and super tweeters. In addition, it has the traditional RCA inputs, Gain adjustment and fixed Crossover (HPF, LPF and Full), characteristic of Taramps products. Another point to be highlighted is the new power and output connector, which, in addition to being robust, guarantees more practicality and safety in installation. All this and much more, so that your pleasure in listening to music becomes even greater.
OPERATION CLASS D NUMBER OF CHANNELS 04 MAX POWER @ 14.4 VDC - 2 OHMS: 800W RMS (4 x 200W RMS) @ 14.4 VDC - 4 OHMS: 544W RMS (4 x 136W RMS) 2 Channel Bridge: 4 Ohms 400W RMS (2 x 400W RMS) INPUT SENSITIVITY (Gain = Max): 250mV (RCA) / 3V (WIRE) (Gain = Max): 4V (RCA) / > 10V (WIRE) SIGNAL/NOISE RATIO >90dB FREQUENCY RESPONSE 10Hz - 20KHz (-3dB) CROSSOVER HIGH PASS (HPF) 90Hz (-12dB/8th) Fixed CROSSOVER LOW PASS (LPF) 90Hz (-12dB/8th) Fixed INPUT IMPEDANCE 10K Ohms (RCA) OUTPUT SHORT PROTECTION SYSTEM MINIMUM SUPPLY VOLTAGE 9VDC MAXIMUM SUPPLY VOLTAGE 16VDC CONSUMPTION AT REST 0.9A MAXIMUM MUSICAL CONSUMPTION @14.4VDC: 38A MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL 76A DIMENSIONS (WXHXD) 138 x 48 x 175mm WEIGHT 0.87Kg |
