Configuration: One host. Two batteries. One charger. One plastic box.
Zui long-distance
(Good weather)
Single prism
5.0km
No prism
not have
digital display
Zui Large: 999999.999 Zui Small: 1mm
accuracy
Prism 2+2ppm
Time
Precision measurement for 0.8 seconds, continuous for 0.3 seconds, tracking for 0.25 seconds
meteorologic correction
Automatic modification of input parameters
Prism constant modification
Automatic modification of input parameters
Temperature and pressure modification
Automatic modification of input parameters
Angle measurement
Angle measurement method
code
Code disk diameter
79mm
Zui small reading
1 "/5" optional
Angle measurement accuracy
2 seconds
Detection method
Horizontal disk: opposite diameter, straight disk: opposite diameter
telescope
imaging
just as
Tube length
154mm
Effective aperture of objective lens
Telescope: 45mm Distance measurement: 50mm
Magnification factor
30*
viewing angle
1 degree 30 minutes
resolution
3"
Zui small focus distance
1m
Automatic vertical compensator
system
Single axis liquid electronic
scope of work
+/-3'
