Features:
1. Indicator light: Usually when the indicator light is on, it means that sampling is running
There are three trigger modes: automatic mode, normal mode, and single mode
3. Trigger slope: The trigger slope determines whether the trigger point is on the rising edge or falling edge of the signal
4. Trigger level: For repetitive signals, the trigger level can stabilize their display. For a single signal, the trigger level can it
5. Save settings: When exiting the setting interface, all parameters of the setting interface and the main interface will be saved in the for EEPROM
6. Waveform generator: for PWM ( for PWM generator) and SIN (sine wave generator), adjust RP1 and RP2 to change the amplitude respectively
Specifications:
Product name: DIY oscilloscope kit
Material: PCB board
Color: blue
PCB size: 57 * 35mm
Finished product size: 57 * 35 * 30mm
Package Content:
1*DIY oscilloscope kit (self-assembly required)
Note:
1. The real color of the item may be slightly different from the pictures shown on the website caused by many factors such as brightness of your monitor and light brightness.
2. Please allow slight manual measurement deviation for the data.
